ürün detay

GR10
Landscape LED Lighting

  • CE
  • TSE
  • IMPACT
  • PROTECTION
  • CLASS 1
  • OUTDOOR
  • POLE
  • ENERGY
  • Made In Turkiye Certificate
GR10
Housing
IP65 Protection
IK09 Impact Protection
Electrostatic powder paint coated die cast aluminum injection housing
Electrical Safety Class I
Body Colors
  • RAL9006
  • RAL7016
  • RAL9005
Optic
PC diffuser with high transmissivity
UGR (CIE Pub.117):21
IEC/EN 62471 Photo-Biologic Protection RG0
Optical Options
  • 120°
Reflector Colors
LED
High color rendering (CRI>80)
SMD LED with a minimum lifetime of 100.000 hours
CRI Color Rendering
  • CRI:80
CCT Light Colors
  • 2700K
  • 3000K
  • 4000K
  • 6500K
Control
Rated Input Voltage 220-240VAC
Power Factor PF>0.95
Input Voltage Range 90-265VAC
Frequency 50-60Hz
ENEC Certified Constant Current Driver Overload Protection (OLP), Overvoltage Protection (OVP), Short Circuit Protection (SCP), Over Temperature Protection (OTP)
Working Environment Temperature -40°C-+60°C
Working Environment Humidity 20% - 95% RH
Control Options
  • 0-10V Prog.
Emergency Lighting
Related Standarts
Driver Standard LVD (EN 61347-1, EN 61347-2-13),EMC ( EN 55015, EN 61547, EN 61000-3-2/3-3)
Luminaire Standard EN 60598-1,EN 60598-2-3

Product Dimensions

Dimensions (mm)
Mountage Size (mm)
Weight (kg)8,4

Packing Details

Quantity Per Carton (pcs.)1
(width)*(lenght)*(height) (cm)61 x 62 x 39
Gross Weight (kg)9,87
Pack Deci (x*y*z) / 300049,17
GR10-060R

Landscape LED Lighting

Power Lumen Efficiency
90W lm lm/W

The values in above table are for standard products and light colors. The values may vary when the LED replaced with a LED having different performance or light color .
